Pick and placer P10

SMT pick & place machine with optical alignment system and precision dispensing head

Precision Automatic Pick & Place Machine

The P1 is a precision automatic SMT pick & place machine designed for small and medium volume production. It features an advanced alignment system, dispensing valve, and automatic nozzle changer with 6 tools. Equipped with top and bottom camera systems for accurate fiducial and optical alignment, it supports all component types with high placement accuracy (+/- 0.03mm) and efficient operation.

Key Features

  • Automatic pick & place head
  • Automatic dispensing head
  • Automatic nozzle changer (6 tools)
  • Top camera system for automatic fiducial detection
  • Bottom camera - optical alignment system for SMD components
  • Gerber and CAD editor compatible with all CAD systems
  • Teach-in mode with electronic manipulator
  • Vision inspection for solder paste and placement accuracy
  • Windows 10 operating system with graphical user interface
  • Remote service via internet
P10 thumbnail

Calibration and Scanning Process

The P1 pick and place machine features an advanced top camera system for automatic fiducial recognition and calibration, ensuring precise alignment before component placement. This process guarantees high accuracy throughout the production run.

Component Placement in Action

Watch the P1 automatic pick & place head in action, accurately positioning components onto the PCB with high speed and precision. The automatic nozzle changer and dispensing valve enable efficient and flexible operation.
