Lead Frame Sensor Assembling: Dispensing, Placing, Soldering
Demonstration of the P30's precision in dispensing, placing, and soldering lead frame sensors, highlighting the integrated dispensing head and multi-tool nozzle changer capabilities.
Precision Pick & Place with Integrated Dispensing
The P30 is equipped with an automatic pick & place head and dispensing head, both featuring a 6-tool automatic nozzle changer. It utilizes a top camera for automatic fiducial recognition and a bottom camera for optical alignment of SMD components. Supported by a smart feeder system via CAN Bus and a user-friendly graphical interface running on Windows 10, this machine offers reliable and efficient operation with remote service capability.
Key Features
- Automatic pick & place head
- Automatic dispensing head
- 6-tool automatic nozzle changer
- Top camera system for automatic fiducial
- Bottom camera for optical alignment
- Gerber and CAD editor support
- Teach-in mode with electronic manipulator
- Smart feeder system with CAN Bus
- Vision inspection of solder paste and component placement
- Operating system: Windows 10
- Remote service via internet
- Graphical user interface
